Схема (деталировка) шуруповёрты KARCHER K 5.200 (1.630-701.0) Housing 2. Подбор по модели, низкие цены в интернет-магазине Дядько.ру с доставкой по Москве и всей России

1	High pressure quick-fitting pipe union A; ;
2	Connection K5; ;
3	Inlet fitting K5 Comp B (spare); ;
4	Fine filter long; ;
5	Screw ATF 4.1x22; ;
6	Filter with weight; ;
7	plastic by pass (spare); ;
8	Hose DN 5; TO ORDER AS CUT GOODS;
9	Flow reducer detergent; Item text1: 1.630-726.0/-729.0;
10	Cylinder head screw M8x65 -8.8-A2E ISO4; ;
11	Spare parts set chemistry; ;
12	Seal 10x2,8; ;
13	Spare part set control head; ;
14	Form seal; ;
15	Pump head Alu FC ric; ;
16	Moulded part complete; ;
17	Grooved ring; ;
18	Supportring 6,7 mm; ;
19	Valve set; ;
20	Joining piece; ;
21	Connection 3/4; ;
22	Cage complete; ;
23	Nozzle insert; ;
24	Distance holder; ;
