1 | HOUSING SET INC. 42 |
2 | BTD140 NAME PLATE |
3 | TAPPING SCREW 3X16 |
4 | SCREW M4X12 |
5 | HOOK |
6 | F/R CHANGE LEVER |
7 | SWITCH TG553FSB-1 |
8 | PAN HEAD SCREW M3.5X5 |
9 | TERMINAL |
10 | RING SPRING 11 |
11 | FLAT WASHER 12 |
12 | COMPRESSION SPRING 13 |
13 | SLEEVE |
14 | BUMPER |
15 | HAMMER CASE COVER |
16 | HAMMER CASE COMPLETE |
17 | NYLON WASHER 14 |
18 | STEEL BALL 3.5 |
19 | ANVIL M |
20 | HAMMER |
21 | STEEL BALL 3.5 |
22 | FLAT WASHER 24 |
23 | COMPRESSION SPRING 24 |
24 | CUP WASHER 14 |
25 | STEEL BALL 5.6 |
26 | SPUR GEAR 22 |
27 | SPINDLE |
28 | PIN 5 |
29 | FLAT WASHER 12 |
30 | INTERNAL GEAR 51 |
31 | BALL BEARING 6901LLB |
32 | O RING 40 |
33 | BEARING BOX COMPLETE INC. 31 |
34 | YOKE UNIT |
35 | ARMATURE |
36 | CARBON BRUSH CB-440 |
37 | BRUSH HOLDER COMPLETE |
38 | RUBBER PIN 4 |
39 | REAR COVER |
40 | TAPPING SCREW 3X16 |
41 | LIGHT CIRCUIT |
42 | HOUSING SET INC. 1 |
A01 | PLASTIC CARRYING CASE |
A02 | DC18RC FAST CHARGER |
A03 | BATTERY BL1830 SET |
A04 | BTD140RFE PLASTIC CASE LABEL |
A08 | BATTERY COVER |
