1 |
Cylinder Assembly |
|
2 |
Kit-Bushing/Seal (Magneto Side) |
|
3 |
Seal-Oil (Magneto Side) |
|
4 |
Sump-Engine Used on Type No(s). 0114, 0151. |
|
4A |
Sump-Engine |
|
4C |
Sump-Engine Used on Type No(s). 0126. |
|
5 |
Head-Cylinder |
|
6 |
Washer (Used After Code Date 07070900). |
|
7 |
Gasket-Cylinder Head |
|
9 |
Gasket-Breather (Used Before Code Date 07071900). (After Date Code Use Liquid Sealant Reference 850) |
|
11 |
Tube-Breather |
|
12 |
Gasket-Crankcase (.015” Thick) (Standard) |
|
13 |
Screw (Cylinder Head) (5/16-18x2.69) (Used After Code Date 07010900). |
|
15 |
Plug-Oil Drain (Square Head) |
|
16 |
Crankshaft (Used After Code Date 12071700). |
|
16B |
Crankshaft (Angled Cut Key-way) |
|
19 |
Kit-Bushing/Seal (PTO Side) |
|
20 |
Seal-Oil (PTO Side) |
|
22 |
Screw (Crankcase Cover/Sump) |
|
23 |
Flywheel (Used After Code Date 12071700). Used on Type No(s). 0113, 0116, 0117, 0758. |
|
23B |
Flywheel (Angled Cut Key-way) (Used Before Code Date 12071800). Used on Type No(s). 0113, 0116, 0117, 0758. |
|
24 |
Key-Flywheel (1.100” Long) |
|
25 |
Piston Assembly (Standard) (Used After Code Date 14093000). |
|
26 |
Ring Set (Standard) (Used After Code Date 06010100). |
|
27 |
Lock-Piston Pin |
|
28 |
Pin-Piston (1.62” Long) (Used After Code Date 14093000). |
|
29 |
Rod-Connecting Used on Type No(s). 0113, 0114, 0116, 0117, 0123, 0124, 0126, 0138, 0147, 0148, 0149, 0150, 0151,0494, 0758, 0804, 0824, 0825, 0899, 0900, 0912, 0979, 1373, 1517, 3147, 3373, 4116, 4117, 4373. |
|
32 |
Screw (Connecting Rod) |
|
33 |
Valve-Exhaust |
|
34 |
Valve-Intake |
|
35 |
Spring-Valve (Intake) |
|
36 |
Spring-Valve (Exhaust) |
|
37 |
Guard-Flywheel |
|
42 |
Keeper-Valve |
|
43 |
Slinger-Governor/Oil |
|
45 |
Tappet-Valve |
|
46 |
Camshaft |
|
50 |
Manifold-Intake |
|
50B |
Manifold-Intake |
|
51 |
Gasket-Intake |
|
51A |
Gasket-Intake |
|
53 |
Stud (Carburetor) (1.00” Thread Length) (Used After Code Date 11121800). |
|
54 |
Screw (Intake Manifold) |
|
73B |
Screen-Rotating (No Longer Available. See Reference 1005A For Sen/ice Flywheel Fan) |
|
74 |
Screw (Rotating Screen) (Used Before Code Date 07040900). |
|
78 |
Screw (Flywheel Guard) |
|
81 |
Lock-Muffler Screw |
|
94A |
Kit-Idle Mixture |
|
95A |
Screw (Throttle Valve) (Used Before Code Date 16010400) |
|
95B |
Screw (Throttle Valve) (Ruixing) (Used After Code Date 16010300). |
|
98A |
Kit-Idle Speed (Used Before Code Date 16010400) |
|
98B |
Kit-Idle Speed (Ruixing) (Used After Code Date 16010300). |
|
104A |
Pin-Float Hinge (Used Before Code Date 16010400) |
|
104B |
Pin-Float Hinge (Ruixing) (Used After Code Date 16010300). |
|
105A |
Valve-Float Needle (Used Before Code Date 16010400) |
|
105B |
Valve-Float Needle (Ruixing) (Used After Code Date 16010300). |
|
108A |
Valve-Choke (Used Before Code Date 16010400) |
|
108B |
Valve-Choke (Ruixing) (Used After Code Date 16010300). |
|
117A |
Jet-Main (Standard) (Used Before Code Date 16010400) |
|
117B |
Jet-Main (Ruixing) (Standard) (Used After Code Date 16010300). |
|
118A |
Jet-Main (High Altitude) |
|
118B |
Jet-Main (Ruixing) (High Altitude) (Used After Code Date 16010300). |
|
121A |
Kit-Carburetor Overhaul (Used Before Code Date 16010400) |
|
121B |
Kit-Carburetor Overhaul (Ruixing Carburetor) (Used After Code Date 16010300). |
|
125 |
Carburetor (Nikki) (Used Before Code Date 16010400 and After Code Date 12081200). |
|
125A |
Carburetor (Nikki) (Used Before Code Date 08042800). Used on Type No(s). 0113G1, 0134, 0804G1. |
|
125B |
Carburetor (Ruixing) (Pump) (Used After Code Date 16010300). Used on Type No(s). 0116,0120,0123, 0125, 0132, 0134, 0138, 0140, 0141, 0143, 0144, 0145, 0148, 0150, 0152, 0157, 0236, 0239, 0240, 0242, 0244, 0557, 0832, 3147, 4116. |
|
127A |
Plug-Welch |
|
130A |
Valve-Throttle (Used Before Code Date 16010400) |
|
130B |
Valve-Throttle (Ruixing) (Used After Code Date 16010300). |
|
131A |
Kit-Throttle Shaft (Used Before Code Date 16010400) |
|
131B |
Kit-Throttle Shaft (Ruixing) (Used After Code Date 16010300). |
|
133A |
Float-Carburetor (Used Before Code Date 16010400) |
|
133B |
Float-Carburetor (Ruixing) (Used After Code Date 16010300). |
|
135 |
Tube-Fuel Transfer (Gravity Feed) |
|
137A |
Gasket-Float Bowl (Used Before Code Date 16010400) |
|
137B |
Gasket-Float Bowl (Ruixing) (Used After Code Date 16010300). |
|
141A |
Kit-Choke Shaft (Used Before Code Date 16010400) |
|
141B |
Kit-Choke Shaft (Ruixing) (Used After Code Date 16010300). |
|
147B |
Jet-Pilot (Ruixing) (Used After Code Date 16010300). |
|
186 |
Connector-Hose |
|
186A |
Connector-Hose |
|
187 |
Line-Fuel (Straight)(15 Inches Long) (Cut to Required Length) |
|
187A |
Line-Fuel (Formed) (21 Inches Long) (Cut to Required Length) |
|
187B |
Line-Fuel (Formed) (10-1/4 Inches Long)(Cut to Required Length) |
|
187D |
Line-Fuel (Formed)(14 Inches Long)(Cut to Required Length) |
|
188 |
Screw (Control Bracket) |
|
192 |
Adjuster-Rocker Arm |
|
202 |
Link-Mechanical Governor |
|
209 |
Spring-Governor (Green) |
|
216 |
Link-Choke |
|
217 |
Spring-Choke Return (Used Before Code Date 16010400) |
|
217B |
Spring-Choke (Ruixing) (Used After Code Date 16010300). |
|
222 |
Bracket-Control |
|
226 |
Rod-Choke (Manual Choke) |
|
227 |
Lever-Governor Control |
|
232 |
Spring-Governor Link |
|
238 |
Cap-Valve |
|
240 |
Filter-Fuel (White, 75 Microns) Used on Type No(s). 0113, 0114, 0151, 0494, 0758, 0804, 0824, 0825, 0899, 0900, 0912, 0979, 1319,1373, 1430, 1517, 2430, 3373, 4373. |
|
240A |
Filter-Fuel (Includes Paper Element With A 40 Micron Rating) Used on Type No(s). 0116,0117,0120, 0123, 0124, 0125, 0126, 0130, 0131, 0132, 0133, 0134, 0138, 0140, 0141, 0143, 0144, 0145, 0147, 0148, 0149, 0150, 0236, 0239, 0240, 0242, 0243, 0244, 0832, 3147, 4116, 4117. |
|
265 |
Clamp-Casing |
|
267 |
Screw (Casing Clamp) |
|
268 |
Casing-Control Wire (Cut To Required Length) |
|
269 |
Wire-Control (Cut To Required Length) |
|
270 |
Nut (Control Wire Casing) |
|
271 |
Lever-Control |
|
276A |
Washer-Sealing (Used Before Code Date 16010400) |
|
276B |
Washer-Sealing (Ruixing) (Used After Code Date 16010300). |
|
300A |
Muffler |
|
300B |
Muffler |
|
300C |
Muffler |
|
304 |
Housing-Blower (Black-Compatible With Flat Panel Style Air Filter) (No Longer Available) (Use Replacement Blower Housing Ref #304B) |
|
304B |
Housing-Blower (Black-Compatible With Panel Style Air Filter) |
|
304G |
Housing-Blower (Black-Compatible With Canister Style Air Filter) |
|
305 |
Screw (Blower Housing) |
|
305A |
Screw (Used On Non-Grommet Style Blower Housing) |
|
305B |
Screw (Blower Housing To Carburetor Elbow) |
|
305C |
Screw (Used On Grommet Style Blower Housing) |
|
306 |
Shield-Cylinder (Used After Code Date 08042700). |
|
307 |
Screw (Cylinder Shield) |
|
309 |
Motor-Starter |
|
310 |
Screw (Starter Motor) |
|
311 |
Brush Set |
|
324 |
Screen-Rotating (Used After Code Date 07040800). |
|
333 |
Armature-Magneto (Used Before Code Date 16070100) |
|
333A |
Armature-Magneto (Used After Code Date 16063000) |
|
333B |
Armature-Magneto (EMC Compliant) (Used After Code Date 16063000) Used on Type No(s). 0157, 0239, 0240, 0242, 0244, 0557, 0899. |
|
334 |
Screw (Magneto Armature) |
|
337 |
Plug-Spark |
|
346 |
Screw (Spark Arrestor) |
|
356B |
Wire-Stop |
|
358 |
Gasket Set-Engine |
|
363 |
Puller-Flywheel |
|
377 |
Key-Timing |
|
383 |
Wrench-Spark Plug |
|
385 |
Screw (Fuel Pump) |
|
385A |
Screw (Fuel Pump) |
|
387 |
Pump-Fuel (Includes Bracket) Used on Type No(s). 0832. |
|
387A |
Pump-Fuel (Used After Code Date 08082400). |
|
404 |
Washer (Governor Crank) |
|
415 |
Plug (Sump) |
|
415A |
Plug (Cover/Retainer) (Used After Code Date 07040800). |
|
431 |
El bow-Intake |
|
431B |
El bow-Intake Used on Type No(s). 0110, 0123, 0124, 0125, 0126, 0147, 0148, 0149, 0150, 0151,0152, 0156, 0157, 0236, 0239, 0240, 0242, 0243, 0244, 0824, 0825, 0899, 0900, 0912, 0979, 1373, 1430, 1517, 2430, 3147, 3373, 4116, 4117, 4373. |
|
445 |
Filter-Air Cleaner Cartridge (Panel Style) |
|
445B |
Filter-Air Cleaner Cartridge (Canister Style) |
|
462 |
Washer (Starter Cable) |
|
474B |
Alternator (Dual Circuit) Used on Type No(s). 0114, 0123, 0138, 0150, 0494, 0804, 0824, 0825, 0899, 0900, 0912, 0979, 1319, 1373, 1430, 1517, 2430, 3147, 3373, 4117, 4373. |
|
474C |
Alternator (5/9 Amp. Regulated Or Tri Circuit) Used on Type No(s). 0113, 0116, 0117, 0120, 0124, 0125, 0126, 0130, 0131, 0132, 0133, 0134, 0140, 0141,0143, 0144, 0145, 0147, 0148, 0149, 0151, 0152, 0156, 0157, 0236, 0239, 0240, 0242, 0243, 0244, 0557, 0758, 0832, 3147, 4116. |
|
501A |
Regulator (5/9 Amp.) |
|
503 |
Strap-Starter |
|
505 |
Nut (Governor Control Lever) |
|
510 |
Drive-Starter |
|
512 |
Hose-Oil Drain |
|
513 |
Clutch-Drive |
|
521 |
Shield-Cable |
|
523 |
Dipstick |
|
524 |
Seal-Dipstick Tube |
|
525 |
Tube-Dipstick Used on Type No(s). 0110, 0116, 0117, 0120, 0123, 0124, 0125, 0126, 0130, 0131,0132, 0133, 0134, 0138, 0140, 0141,0143, 0144, 0145, 0147, 0148, 0149, 0150, 0152, 0157, 0236, 0239, 0240, 0242, 0243, 0244, 0832, 3147, 4116, 4117. |
|
526A |
Screw (Regulator) |
|
552 |
Bushing-Governor Crank |
|
559 |
Screw (.375 Inches Remote Choke Stop) |
|
559A |
Screw (.419 Inches Remote Choke Stop) |
|
562 |
Bolt (Governor Control Lever) |
|
563A |
Screw (Debris Guard) |
|
579 |
Nut (Starter Cable) |
|
584 |
Cover-Breather Passage (Use With Liquid Sealant Reference 850) |
|
601 |
Clamp-Hose |
|
613 |
Screw (Muffler) |
|
613A |
Screw (Muffler) |
|
613B |
Screw (Muffler) |
|
614 |
Pin-Cotter |
|
616 |
Crank-Governor |
|
617 |
Seal-0 Ring (Intake Manifold) |
|
633 |
Seal Choke |
|
633B |
Seal-Throttle Shaft (Nikki) (Used Before Code Date 16010400) |
|
633C |
Seal-Choke/Throttle Shaft (Used After Code Date 16010300). (Ruixing) |
|
633D |
Seal-Choke/Throttle Shaft (Used After Code Date 16010300). (Ruixing) |
|
633E |
Seal-Choke/Throttle Shaft (Ruixing) (Used After Code Date 16010300). |
|
634B |
Spring/Seal Assembly |
|
635 |
Boot-Spark Plug |
|
643 |
Retainer-Air Filter |
|
652 |
Screw (Manual Choke Rod) |
|
654 |
Nut (Carburetor) |
|
676 |
Deflector-Muffler |
|
676A |
Deflector-Muffler |
|
677 |
Screw (Muffler Deflector) |
|
684 |
Screw (Breather Assembly) |
|
691 |
Seal-Governor Shaft |
|
697 |
Screw (Drive Cap) |
|
718 |
Pin-Locating |
|
729 |
Clip-Wire |
|
729A |
Clip-Wire |
|
740A |
Nut |
|
741 |
Gear-Timing |
|
750 |
Screw (Oil Pump Cover) |
|
757 |
Link-Counterweight |
|
758 |
Counterweight (Used After Code Date 14100500). |
|
759 |
Pin-Counterweight |
|
773 |
Retainer |
|
783 |
Gear-Pinion |
|
789 |
Harness-Wiring |
|
789B |
Harness-Wiring |
|
797 |
Nut (Brush Retainer) |
|
801 |
Cap-Drive |
|
802 |
Cap-End |
|
823 |
Screw (Muffler Adapter) |
|
830 |
Stud-Rocker Arm |
|
832 |
Guard-Muffler |
|
832A |
Guard-Muffler |
|
836 |
Screw (Muffler Guard) |
|
836A |
Screw (Muffler Guard) |
|
842 |
Seal-0 Ring (Dipstick Tube) |
|
847 |
Dipstick/Tube Assembly Used on Type No(s). 0116, 0117, 0123, 0124, 0125, 0126, 0130, 0131,0132, 0133, 0134, 0138, 0140, 0141,0143, 0144, 0147, 0148, 0149, 0150, 0152, 0157, 0236, 0239, 0240, 0242, 0243, 0244, 0832, 3147, 4116, 4117. |
|
850 |
Sealant-Liquid (Rocker Cover Gasket and Breather Gasket) (Used After Code Date 07071800). |
|
851 |
Terminal-Spark Plug |
|
864 |
Adapter-Muffler (Length 2.25 Inches) |
|
868 |
Seal-Valve |
|
877 |
Wire/Connector-Alternator (Dual Circuit) |
|
877D |
Wire/Connector- Alternator |
|
878 |
Harness-Alternator (Dual Circuit) |
|
878A |
Harness-Alternator (Tri Circuit) |
|
883 |
Gasket-Exhaust |
|
884 |
Clamp-Muffler |
|
914 |
Screw (Rocker Cover) |
|
918 |
Hose-Vacuum |
|
943 |
Seal-O Ring (Oil Pump Cover) |
|
947A |
Solenoid-Fuel (Used Before Code Date 16010400) |
|
947B |
Solenoid-Fuel (Ruixing) (Used After Code Date 16010300). |
|
949A |
Guard-Debris Screen |
|
958 |
Valve-Fuel Shut Off (Plastic) |
|
964 |
Cap-Connector (EVAP) |
|
965 |
Cover-Oil Pump |
|
967 |
Filter-Pre Cleaner |
|
968 |
Cover-Air Cleaner (Black-Compatible With Panel Style Filters) |
|
968B |
Cover-Air Cleaner (Black-Compatible With Canister Style Filers) Used on Type No(s). 0123, 0124, 0125, 0126, 0147, 0148, 0149, 0150, 0151, 0236, 0239, 0240, 0242, 0243, 0244,^ 0824,0825, 0899, 0900, 0912, 0979, 1373, 1430, 1517, 2430, 3147, 3373, 4116, 4117, 4373. |
|
975B |
Bowl-Float (Ruixing) (Used After Code Date 16010300). |
|
994 |
Arrestor-Spark |
|
1005 |
Fan-Flywheel (Used After Code Date 07040800). |
|
1005A |
Fan-Flywheel (Used Before Code Date 07040900). |
|
1005B |
Fan-Flywheel (No Longer Available) (See Reference1005A For Service Flywheel Fan). |
|
1017 |
Screen-Oil Pump |
|
1022 |
Gasket-Rocker Cover (Used Before Code Date 07091000). (After Date Code Use Liquid Sealant Reference 850) |
|
1023 |
Cover-Rocker |
|
1024A |
Pump-Oil |
|
1026 |
Rod-Push (Intake) |
|
1027 |
Filter-Oil (Standard) |
|
1029 |
Arm-Rocker |
|
1034 |
Guide-Push Rod |
|
1035 |
Shaft-Pump |
|
1036 |
Label-Emissions (Available From A Briggs & Stratton Authorized Dealer) |
|
1040B |
Plate-Trim |
|
1044 |
Screw (Flywheel) |
|
1051 |
Ring-Retaining |
|
1054 |
Tie-Cable |
|
1059 |
Kit-Screw/Washer |
|
1070 |
Screw (Flywheel Fan) (Used Before Code Date 07040900). |
|
1070A |
Screw (Used Before Code Date 8061000 and After Code Date 07040800). |
|
1090 |
Retainer-Brush |
|
1091 |
Cap-Limiter |
|
1095 |
Gasket Set-Valve |
|
1119 |
Screw (Alternator) |
|
1127 |
Screw (Float Bowl) |
|
1139 |
Washer |
|
1263 |
Reed-Breather |
|
1264 |
Screw (Breather Reed) |
|
1266 |
Seal-0 Ring (Intake Elbow) |
|
1266A |
Seal-0 Ring (Intake Elbow) |
|
1267 |
Latch-Blower Housing (Black) |
|
1270 |
Plug-AVS Counterweight |
|
1319 |
Label-Warning |
|
1448 |
Washer (Magneto Armature) |
|
1975A |
Bowl-Float (Used Before Code Date 16010400) |
|
|
Pin-Piston (Used Before Code Date 08042800). |
|
|
Rod-Connecting Used on Type No(s). 0120, 0125, 0130, 0131,0132, 0133, 0134, 0140, 0141, 0143, 0144, 0145, 0152, 0156, 0157, 0236, 0239, 0240, 0242, 0243, 0244, 0557, 0832, 0979, 1319, 1430, 2430. |
|
|
Stud (Carburetor) (1.75” Thread Length) (Used Before Code Date 11121900). |
|
|
Spring Governor (Natural) Used on Type No(s). 0149.^ |
|
|
Spring Governor (Red) Used on Type No(s). 0110,0123,0124, 0126, 0138, 0147, 0148, 0150, 3147, 4117. |
|
|
Spring Governor (Gold) Used on Type No(s). 0116,0149,0824, 0899, 4116. |
|
|
Spring Governor (Yellow) Used on Type No(s). 0120, 0131,0133, 0143, 0151,0157, 0242, 0243, 0244. |
|
|
Jet-Main (Standard) (Used Before Code Date 16010400 and After Code Date 08042700). Used on Type No(s). 0113G1, 0134, 0804G1. |
|
|
Jet-Main (Standard) (Used Before Code Date 08042800). Used on Type No(s). 0113G1, 0134, 0804G1. |
|
|
Jet-Main (Standard) (Used After Code Date 08092800). Used on Type No(s). 0113B1, 0113E1, 0114B1,0494, 0804B1,0804B2, 0804E1. |
|
|
Jet-Main (Standard) (Used Before Code Date 08092900). Used on Type No(s). 0114B1, 0804B1, 0804B2, 0804E1. |
|
|
Jet-Main (Standard) (Used Before Code Date 16010400 and After Code Date 09012400). Used on Type No(s). 0116, 0117B1, 0130, 0131,0132, 0133, 0138, 0832. |
|
|
Dipstick/Tube Assembly Used on Type No(s). 0113, 0114, 0151, 0156, 0494, 0758, 0804, 0824, 0825, 0899, 0900, 0912, 0979,1319, 1373, 1430,1517, 2430, 3373, 4373. |
|
|
Jet-Main (Standard) (Used Before Code Date 09012500). Used on Type No(s). 0116, 0117B1, 0132, 0133, 0138, 0832. |
|
|
Jet-Main (Standard) (Used Before Code Date 08092900 and After Code Date 07040800). Used on Type No(s). 0113B1, 0113E1, 0494. |
|
|
Jet-Main (Standard) (Used Before Code Date 09012500 and After Code Date 07040800). Used on Type No(s). 0130, 0131. |
|
|
Jet-Main (Standard) (Used Before Code Date 07040900). Used on Type No(s). 0113B1, 0113E1, 0130, 0131,0494. |
|
|
Jet-Main (Ruixing) (Standard) (Used After Code Date 16010300). Used on Type No(s). 0116, 0132, 0134, 0138, 0832. |
|
|
Jet-Main (High Altitude) (Used Before Code Date 16010400 and After Code Date 08042700). Used on Type No(s). 0113G1, 0134, 0804G1. |
|
|
Jet-Main (High Altitude) (Used Before Code Date 08042800). Used on Type No(s). 0113G1, 0134, 0804G1. |
|
|
Jet-Main (High Altitude) (Used After Code Date 08092800) Used on Type No(s). 0113B1, 0113E1, 0114B1, 0494, 0804B1,0804B2, 0804E1. |
|
|
Jet-Main (High Altitude) (Used Before Code Date 08092900). Used on Type No(s). 0114B1, 0804B1, 0804B2, 0804E1. |
|
|
Jet-Main (High Altitude) (Used Before Code Date 16010400 and After Code Date 09012400). Used on Type No(s). 0116, 0117B1,0130, 0131,0132, 0133, 0138, 0832. |
|
|
Tube-Dipstick Used on Type No(s). 0113, 0114, 0151, 0156, 0494, 0758, 0804, 0824, 0825, 0899, 0900, 0912, 0979,1319, 1373, 1430,1517, 2430, 3373, 4373. |
|
|
Tube-Fuel Transfer (Pump Feed) (Used After Code Date 12081200). |
|
|
Jet-Main (High Altitude) (Used Before Code Date 09012500). Used on Type No(s). 0116, 0117B1, 0132, 0133, 0138, 0832. |
|
|
Jet-Main (High Altitude) (Used Before Code Date 08092900 and After Code Date 07040800). Used on Type No(s). 0113B1, 0113E1, 0494. |
|
|
Jet-Main (High Altitude) (Used Before Code Date 09012500 and After Code Date 07040800). Used on Type No(s). 0130, 0131. |
|
|
Jet-Main (High Altitude) (Used Before Code Date 07040900). Used on Type No(s). 0113B1,0113E1, 0130, 0131, 0494. |
|
|
Kit-Throttle Shaft (Used Before Code Date 07040900). Used on Type No(s). 0113, 0130, 0131, 0494. |
|
|
Kit-Throttle Shaft (Used Before Code Date 16010400 and After Code Date 07040800). Used on Type No(s). 0113, 0130, 0131, 0494. |
|
|
Jet-Main (Ruixing) (High Altitude) (Used After Code Date 16010300). Used on Type No(s). 0116,0132,0134, 0138, 0832. |
|
|
Carburetor (Nikki) (Used Before Code Date 16/010400) Used on Type No(s). 0151,0152, 0156, 0157, 0557, 0899, 0912, 1373, 1517, 2430, 3373, 4373. |
|
|
Valve-Throttle (Used Before Code Date 07040900). Used on Type No(s). 0113,0130,0131, 0494. |
|
|
Valve-Throttle (Used Before Code Date 16010400 and After Code Date 07040800). Used on Type No(s). 0113,0130,0131, 0494. |
|
|
Carburetor (Nikki) (Used Before Code Date 16010400 and After Code Date 08042700). Used on Type No(s). 0113G1, 0134, 0804G1. |
|
|
Carburetor (Nikki) (Used Before Code Date 16010400 and After Code Date 08092800). Used on Type No(s). 0113B1, 0113E1, 0114B1, 0494B1, 0494E1, 0804B1, 0804B2, 0804E1. |
|
|
Carburetor (Ruixing) (Gravity) (Used After Code Date 16010300). Used on Type No(s). 0151,0156, 0899, 0912, 1373, 1517, 2430, 3373, 4373. |
|
|
Carburetor (Nikki) (Used Before Code Date 16010400 and After Code Date 09012400). Used on Type No(s). 0116, 0117B1, 0130, 0131,0132, 0133, 0138, 0832. |
|
|
Carburetor (Nikki) (Used Before Code Date 07040900). Used on Type No(s). 0113B1, 0113E1, 0130, 0131,0494. |
|
|
Carburetor (Nikki) (Used Before Code Date 09012500 and After Code Date 07040800). Used on Type No(s). 0130, 0131. |
|
|
Carburetor (Nikki) (Used Before Code Date 08092900 and After Code Date 07040800). Used on Type No(s). 0113B1, 0113E1, 0494. |
|
|
Carburetor (Nikki) (Used Before Code Date 09012500). Used on Type No(s). 0116, 0117B1,0132, 0133, 0138, 0832. |
|
|
Carburetor (Nikki) (Used Before Code Date 08092900). Used on Type No(s). 0114B1, 0804B1, 0804B2, 0804E1. |
|
|
Rod-Push (Exhaust) |
|
|
Filter-Oil (Premium) |
|
|
Tube-Fuel Transfer (Pump Feed) (Used Before Code Date 12081300). |
|
|
Pump-Fuel (Includes Bracket) (Used Before Code Date 08082500). |
|
|
Plug-Spark Used on Type No(s). 0113G1, 0117G1, 0124, 0126, 0149, 0157, 0239, 0240, 0242, 0243, 0244, 0557, 0824, 0899. |
|
|
Plug-Spark Used on Type No(s). 0113B1, 0113E1, 0117B1. |
|
|
Plug-Spark Used on Type No(s). 0110, 0116, 0123, 0138, 0148, 0150, 0151,0156, 0758, 0825, 0900, 0979, 1319, 1430, 1517, 2430, 4116, 4117. |
|
|
Shield-Cylinder (Used Before Code Date 08042800). |
|
|
Cylinder Assembly (Used Before Code Date 08042800). Must Be Used With The After 08042700 Cylinder Shield, Ref 306. |
|
|
Screw (Cylinder Head) (5/16-18x2.25) (Used Before Code Date 07011000). |
|
|
Crankshaft (Used Before Code Date 12071800). 591763Crankshaft (Used After Code Date 12071700). Used on Type No(s). 0120, 0125, 0131, 0132, 0133, 0134, 0140, 0141,0143, 0144, 0145, 0152, 0157, 0236, 0239, 0240, 0242, 0244, 0557, 0832, 1319, 1430, 2430. |
|
|
Crankshaft (Used Before Code Date 12071800). Used on Type No(s). 0120, 0125, 0130, 0131,0132, 0133, 0134, 0140, 0141, 0143, 0144, 0145, 0236, 0239, 0240, 0242, 0244, 0832, 1319, 1430, 2430. |
|
|
Flywheel (Straight Cut Key-way) (No Longer Available) (For Replacement Order Ref #23B) (Used Before Code Date 12071800). Used on Type No(s). 0113, 0116, 0117, 0758. |
|
|
Flywheel (Used After Code Date 12071700). Used on Type No(s). 0114, 0123, 0138, 0150, 0494, 0804, 1319, 4117. |
|
|
Flywheel (Used Before Code Date 12071800). Used on Type No(s). 0114, 0123, 0138, 0150, 0494, 0804, 1319, 4117. |
|
|
Flywheel (Used After Code Date 12071700). Used on Type No(s). 0824, 0825, 0899, 0900, 0912, 0979, 1373, 1430, 1517, 2430, 3373, 4373. |
|
|
Flywheel (Used Before Code Date 12071800). Used on Type No(s). 0824, 0825, 0899, 0900, 0912, 0979, 1373, 1430, 1517, 2430, 3373, 4373. |
|
|
Flywheel (Used After Code Date 12071700). Used on Type No(s). 0110, 0120, 0124, 0125, 0126, 0130, 0131,0132, 0133, 0134, 0140, 0141, 0143, 0144, 0145, 0147, 0148, 0149, 0151,0152, 0156, 0157, 0236, 0239, 0240, 0242, 0243, 0244, 0557, 0832, 3147, 4116. |
|
|
Flywheel (Used Before Code Date 12071800). Used on Type No(s). 0110, 0120, 0124, 0125, 0126, 0130, 0131,0132, 0133, 0134, 0140, 0141, 0143, 0144, 0145, 0147, 0148, 0149, 0151,0236, 0239, 0240, 0242, 0243, 0244, 0832, 3147, 4116. |
|
|
Key-Flywheel (0.555” Long) |
|
|
Piston Assembly (Used Before Code Date 14100100). |
|
|
Piston Assembly (.020” Oversize) (Used After Code Date 14093000). |
|
|
Piston Assembly (.020” Oversize) (Used Before Code Date 14100100). |
|
|
Counterweight (Used Before Code Date 14100600). |
|
|
Counterweight (Used After Code Date 14093000). Used on Type No(s). 0156. |
|
|
Counterweight (Used Before Code Date 14100100). Used on Type No(s). 0156, 2430. |
|
|
Ring Set (Standard) (Used Before Code Date 06010200). |
|
|
Ring Set (.020” Oversize) (Used After Code Date 14093000). |
|
|
Ring Set (.020” Oversize) (Used Before Code Date 14100100). |
|
|
Pin-Piston (1.97” Long) (Used Before Code Date 14100100 and After Code Date 08042700). |
