1 |
Cylinder Assembly (Used After Code Date 11063000). |
|
2 |
Kit- Bushing/Seal (Magneto Side) |
|
3 |
Seal-Oil (Magneto Side) |
|
4 |
Sump-Engine |
|
4A |
Sump-Engine (Auxilliary PTO) |
|
5 |
Head-Cylinder (Used After Code Date 11063000). |
|
7 |
Gasket-Cylinder Head (Used After Code Date 11063000). |
|
8 |
Breather Assembly (Used After Code Date 11063000). |
|
9 |
Gasket- Breather (Used After Code Date 11063000). |
|
10 |
Screw (Breather Assembly) |
|
11 |
Tube-Breather |
|
11B |
Tube-Breather |
|
12 |
Gasket-Crankcase |
|
13 |
Screw (Cylinder Head) (Used After Code Date 11063000). |
|
15 |
Plug-Oil Drain (Square Socket) |
|
15A |
Plug-Oil Drain (Hex Socket) |
|
16 |
Crankshaft (Used After Code Date 97011200). |
|
20 |
Seal-Oil (PTO Side) |
|
20A |
Seal-Oil (PTO Side) (Auxilliary PTO) |
|
22 |
Screw (Crankcase Cover/ Sump) |
|
23A |
Flywheel |
|
24 |
Key-Flywheel |
|
25 |
Piston Assembly (Standard) (Used After Code Date 11063000). |
|
26 |
Ring Set (Standard) (Used After Code Date 11063000). |
|
27 |
Lock-Piston Pin (Used After Code Date 09041600). |
|
28 |
Pin-Piston (Standard) (Used After Code Date 09041600). |
|
29 |
Rod-Connecting (Standard) (Used After Code Date 09041600). |
|
32 |
Screw (Connecting Rod) |
|
32A |
Screw (Connecting Rod) (Used After Code Date 00042200). |
|
33 |
Valve-Exhaust (Used After Code Date 11063000). |
|
34 |
Valve-Intake (Used After Code Date 11063000). |
|
35 |
Spring-Valve (Intake) |
|
36 |
Spring-Valve (Exhaust) |
|
37 |
Guard-Flywheel |
|
40 |
Retainer-Valve |
|
43 |
SI inger-Govemor/Oil |
|
45 |
Tappet-Valve |
|
46 |
Camshaft (Used After Code Date 96060200). |
|
46A |
Camshaft (Clockwise) (Used After Code Date 96060200). Used on Type No(s). 0823. 1923. |
|
50 |
Manifold-lntake |
|
51 |
Gasket-Intake |
|
54 |
Screw (Intake Manifold) |
|
55 |
Housing-Rewind Starter |
|
58 |
Rope-Starter (Cut To Required Length) |
|
60 |
Grip-Starter Rope |
|
60C |
Grip-Starter Rope |
|
65 |
Screw (Rewind Starter) |
|
78 |
Screw (Flywheel Guard) |
|
81 |
Lock-Muffler Screw |
|
83 |
Shaft-Auxiliary Drive Used on Type No(s). 0679. 0823.1923. 1947.1949.1989. |
|
94 |
Kit-Idle Mixture |
|
95 |
Screw (Throttle Valve) |
|
97 |
Shaft-Throttle (Metal) |
|
98 |
Kit-Idle Speed |
|
98A |
Kit-Idle Speed |
|
101 |
Pin-Shaft |
|
104 |
Pin-Float Hinge |
|
108 |
Valve-Choke |
|
108A |
Valve-Choke (Used After Code Date 08031200). |
|
109 |
Shaft-Choke |
|
109A |
Shaft-Choke |
|
109B |
Shaft-Choke (Used After Code Date 08031200). |
|
117 |
Jet-Main (Standard) |
|
117A |
Jet-Main (Standard) |
|
117B |
Jet-Main (Standard) |
|
118 |
Jet-Main (High Altitude) |
|
118A |
Jet-Main (High Altitude) |
|
118B |
Jet-Main (High Altitude) |
|
121 |
Kit-Carburetor Overhaul |
|
125 |
Carburetor (Primer System) |
|
125A |
Carburetor (Choke System) Used on Type No(s). 1701,1714,1715,1786, 1932,1961,2013,2044, 2324,2329,2333,2334, 2349,2367,2383,2391, 2635,2673,2681,2683, 3178,3183. |
|
125B |
Carburetor (Autochoke System) |
|
127 |
Plug-Welch |
|
130 |
Valve-Throttie |
|
133 |
Float-Carburetor |
|
134 |
Kit-Needle/Seat |
|
137 |
Gasket-Float Bowl (1/8” Thick) |
|
146 |
Key-Timing |
|
159 |
Bracket-Air Cleaner Primer |
|
163 |
Gasket-Air Cleaner |
|
187 |
Line-Fuel (Cut to Required Length) |
|
187A |
Line-Fuel (Molded) |
|
187B |
Line-Fuel (Includes Filter) |
|
187C |
Line-Fuel (Molded) |
|
188 |
Screw (Control Bracket) |
|
190 |
Screw (Fuel Tank) |
|
202 |
Link- Mechanical Governor |
|
209 |
Spring- Governor Used on Type No(s). 2329. |
|
209A |
Spring- Governor Used on Type No(s). 1167. |
|
209B |
Spring -Governor |
|
217 |
Spring-Choke Return |
|
222 |
Bracket-Control (Remote/Manual Friction) (Primer) |
|
222A |
Bracket-Control (Remote, Choke A Matic, Non Compliance) |
|
222B |
Bracket-Control (Fixed Speed Auto Primer Control) |
|
222C |
Bracket-Control (Variable Speed) (5 Position Manual Choke) |
|
222D |
Bracket-Control (Fixed Speed) |
|
222E |
Bracket-Control (Manual Friction, 5 Position Manual Choke) |
|
227 |
Lever- Governor Control |
|
231 |
Screw (Choke Valve) |
|
236 |
Link-Lockout |
|
240 |
Filter-Fuel |
|
259 |
Bracket-Casing Clamp (Control Wire Casing) |
|
265 |
Clamp-Casing |
|
265A |
Clamp-Casing |
|
265B |
Clamp-Casing |
|
267 |
Screw (Casing Clamp) |
|
268 |
Casing-Control Wire (Cut to Required Length) |
|
269 |
Wire-Control (Cut to Required Length) |
|
270 |
Nut (Control Wire Casing) |
|
271 |
Lever-Control |
|
276 |
Washer-Sealing |
|
287 |
Screw (Dipstick Tube) |
|
291 |
Thermostat |
|
300 |
Muffler (Super Lo Tone) |
|
300A |
Muffler (Square Lo Tone) |
|
300B |
Muffler (Catalyst) |
|
304 |
Housing-Blower |
|
305 |
Screw (Blower Housing) |
|
306 |
Shield-Cylinder |
|
306A |
Shield-Cyiinder |
|
307 |
Screw (Cylinder Shield) |
|
309 |
Motor-Starter (Used Before Code Date 07052900). |
|
309A |
Motor-Starter (Used After Code Date 07052800 and Before Code Date 10112800). |
|
309B |
Motor-Starter (Used After Code Date 10112700). |
|
310 |
Bolt (Starter Motor) |
|
332 |
Nut (Flywheel) |
|
333 |
Armature-Magneto |
|
333A |
Armature-Magneto (Screw On Spark Plug Boot) |
|
334 |
Screw (Magneto Armature) |
|
337 |
Plug-Spark (Used After Code Date 11063000). |
|
346 |
Screw (Spark Arrestor) |
|
347 |
Switch-Rocker |
|
356 |
Wire-Stop |
|
356A |
Wire-Stop |
|
356B |
Wire-Stop |
|
356D |
Wire-Stop |
|
356F |
Wire-Stop |
|
356H |
Wire-Stop |
|
358 |
Gasket Set-Engine (Used After Code Date 11063000). |
|
359 |
Washer (Ground Terminal) |
|
363 |
Flywheel Puller |
|
365 |
Screw (Carburetor) |
|
373 |
Nut (Ground Terminal) |
|
374 |
Washer (Camshaft) |
|
383 |
Wrench-Spark Plug |
|
404 |
Washer (Governor Crank) |
|
425A |
Screw (Air Cleaner Cover) |
|
443A |
Screw (Air Cleaner Primer Base) |
|
445A |
Filter-Air Cleaner Cartridge |
|
455 |
Cup-Flywheel |
|
456 |
Plate-Pawl Friction |
|
459 |
Plate-Ratchet |
|
474 |
Alternator |
|
497 |
Screw (Stop Switch Bracket) |
|
500 |
Washer (Key Switch) |
|
505 |
Nut (Governor Control Lever) |
|
507 |
Insulator |
|
510 |
Drive-Starter |
|
513 |
Clutch-Drive |
|
520 |
Terminal-Ground |
|
523 |
Dipstick |
|
524 |
Seal-Dipstick Tube |
|
525 |
Tube-Dipstick |
|
544 |
Armature-Starter |
|
545 |
Washer Set (Starter Motor) |
|
562 |
Bolt (Governor Control Lever) |
|
564 |
Screw (Control Cover) |
|
564A |
Screw (Control Cover) |
|
564B |
Screw (Control Cover) |
|
584 |
Cover-Breather Passage |
|
585 |
Gasket-Breather Passage |
|
592 |
Nut (Rewind Starter) |
|
597 |
Screw (Pawl Friction Plate) |
|
601 |
Clamp-Hose |
|
601A |
Clamp-Hose |
|
604 |
Cover-Control |
|
604A |
Cover-Control |
|
604B |
Cover-Control |
|
604C |
Cover-Control |
|
604D |
Cover-Control |
|
608 |
Starter-Rewind |
|
613 |
Screw (Muffler) |
|
613A |
Screw (Muffler) |
|
613B |
Screw (Muffler) |
|
615 |
Retai ner- Governor Shaft |
|
616 |
Crank-Governor |
|
617 |
Seal-0 Ring (Intake Manifold) |
|
621 |
Switch-Stop |
|
627 |
Bracket-Stop Switch |
|
633 |
Seal-Choke/Throttle Shaft |
|
633A |
Seal-Choke/Throttle Shaft |
|
635 |
Boot-Spark Plug |
|
635A |
Boot-Spark Plug (Screw On Style) |
|
651 |
Screw (Starter Gear Cover) |
|
664 |
Nut (Key Switch) |
|
668 |
Spacer |
|
670 |
Spacer-Fuel Tank |
|
676 |
Deflector-Muffler (Louvered) |
|
676A |
Deflector-Muffler (Side Out) |
|
676B |
Deflector-Muffler (Direct Out) |
|
676C |
Deflector-Muffler (Side Out) (Extended) |
|
677 |
Screw (Muffler Deflector) |
|
684 |
Screw (Breather Passage Cover) |
|
689 |
Spring-Friction |
|
692 |
Spring-Detent |
|
697 |
Screw (Drive Cap) |
|
715 |
Screw (Shaft Stop) |
|
718 |
Pin-Locating |
|
721 |
Stop-Shaft |
|
741 |
Gear-Timing (Metal) (Used After Code Date 08021700). |
|
742 |
Retainer-E Ring |
|
743 |
Gear-Drive (Counterclockwise) |
|
745 |
Screw (Brake) |
|
783 |
Gear-Pinion |
|
783A |
Gear-Pinion |
|
784 |
Cover-Starter Gear |
|
785 |
Gasket-Starter Cover |
|
789A |
Harness-Wiring (Used Before Code Date 00040700). |
|
789B |
Harness-Wiring |
|
801 |
Cap-Drive |
|
802 |
Cap-End (Used After Code Date 00040600). |
|
803 |
Housing-Starter (Used After Code Date 00040600). |
|
832 |
Guard-Muffler (Used After Code Date 11063000). |
|
832A |
Guard-Muffler |
|
832B |
Guard-Muffler |
|
832E |
Guard-Muffler |
|
836 |
Screw (Muffler Guard) |
|
836A |
Screw (Muffler Guard) |
|
836B |
Screw (Muffler Guard) |
|
836C |
Screw (Muffler Guard) |
|
842 |
Seal-0 Ring (Dipstick Tube) |
|
843 |
Sleeve-Lever (Speed Control) |
|
843A |
Sleeve-Lever (Choke) |
|
847 |
Dipstick/Tube Assembly |
|
851 |
Terminal-Spark Plug |
|
851A |
Terminal-Spark Plug |
|
853 |
Adapter-Wire |
|
868 |
Seal-Valve (Used After Code Date 11063000). |
|
869 |
Seat-Valve (Intake) |
|
870 |
Seat-Valve (Exhaust) |
|
871 |
Bushing-Valve Guide (Exhaust) (Used After Code Date 11063000). |
|
883 |
Gasket-Exhaust |
|
892 |
Switch-Key |
|
910 |
Stud (Alternator) |
|
921 |
Cover-Blower Housing |
|
921A |
Cover-Blower Housind |
|
921B |
Cover-Blower Housind Used on Type No(s). 2012.2320.2331. 2626.2391.2396. |
|
921C |
Cover-Blower Housing |
|
921E |
Cover-Blower Housind |
|
921F |
Cover-Blower Housind |
|
921G |
Cover-Blower Housind |
|
921H |
Cover-Blower Housind |
|
921J |
Cover-Blower Housind |
|
921K |
Cover-Blower Housind |
|
921N |
Cover-Blower Housind |
|
921P |
Cover-Blower Housind |
|
921R |
Cover-Blower Housind |
|
921U |
Cover-Blower Housind |
|
922 |
Spring-Brake |
|
922A |
Spring-Brake |
|
923 |
Brake |
|
923A |
Brake |
|
923B |
Brake (Used After Code Date 08043000). Used on Type No(s). 0680.1700.1706. 1721.1724.1737. 1746.1747.1748. 1749.1753.1782. 1816.1818.1820. 1827.1829.1830. 1831.1835.1837. 1841.1844. 1845. 1846.1850.1852. 1906.1907.1908. 1910.1911.1912. 1913.1915.1917. 1930.1963.1965. 1966.1972.1975. 2011.2012. 2018. 2019. 2021.2022. 2024. 2028. 2029. 2033. 2035. 2041, 2148. 2149.2308. 2639.3170. 3185. 3189. 3509. |
|
925 |
Cover-Linkage (Used After Code Date 07072200). |
|
930 |
Guard-Rewind (Round) |
|
930A |
Guard-Rewind (Teardrop) |
|
935 |
Switch-lnterlock (Used Before Code Date 08050100). |
|
937 |
Spline-Starter |
|
937A |
Spline-Starter |
|
940 |
Screw (Casing Clamp Bracket) |
|
946 |
Stop-Rope |
|
957 |
Cap-Fuel Tank (Plastic) |
|
957A |
Cap-Fuel Tank (Plastic) |
|
957B |
Cap-Fuel Tank (Plastic) |
|
958 |
Valve-Fuel Shut Off (Plastic) |
|
966A |
Base-Air Cleaner Primer |
|
966B |
Base-Air Cleaner Primer |
|
967A |
Filter-Pre Cleaner |
|
968B |
Cover-Air Cleaner |
|
969 |
Screw (Blower Housing Cover) |
|
969A |
Screw (Blower Housing Cover) |
|
970 |
Screw (Air Cleaner Primer Bracket) |
|
972 |
Tank-Fuel (Plastic) |
|
972B |
Tank-Fuel (Plastic) |
|
975 |
Bowl-Float |
|
976 |
Primer-Carburetor |
|
977 |
Gasket Set-Carburetor |
|
986 |
Filter-Debris Foam |
|
990 |
Key Set |
|
990A |
Key Set (Touch N Mow) |
|
994 |
Arrestor-Spark |
|
1005 |
Fan-Flywheel |
|
1009 |
Screw (Starter Motor) |
|
1019 |
Kit-Label |
|
1036 |
Label-Emissions (Available From A Briggs & Statton Authorized Dealer) |
|
1058 |
Operator’s Manual (Used After Code Date 11063000). |
|
1059 |
Kit-Screw/Washer |
|
1095 |
Gasket Set-Valve (Used After Code Date 11063000). |
|
1102 |
Pilot-Guide Used on Type No(s). 1167, 1715.2367. 2673. |
|
1119 |
Screw (Alternator) |
|
1160 |
Screw (Interlock Switch) |
|
1210 |
Pulley/Spring Assembly (Pulley) |
|
1211 |
Pulley/Spring Assembly (Spring) |
|
1236 |
Starter-Mechanical (Touch N Mow) (Do Not Service Individual Parts. Only As A Whole) |
|
1319 |
Label-Warning |
|
1330 |
Manual-Repair |
|
1386 |
Vane-Air (Autochoke System) |
|
1387 |
Spring-Air Vane |
|
1388 |
Screw (Air Vane) (Autochoke System) |
|
|
Screw (Muffler) Used on Type No(s). 1844. |
|
|
Screw (Muffler) Used on Type No(s). 1706.1738.1739. 1748.1750.1807. 1808.1816.1817. 1823.1824.1825. 1826.1827.1829. 1831,1835.1845. 1846.1847.1849. 1851,1963.1964. 1965. 2011.2015. 2016. 2017. 2018. 2021,2022. 2028. 2034. 2041. |
|
|
Screw (Control Cover) |
|
|
Gasket Set-Engine (Used Before Code Date 11070100). |
|
|
Plug-Spark (EMS) (Used Before Code Date 11070100). |
|
|
Bracket-Stop Switch Used on Type No(s). 1701.1836.1961. |
|
|
Plug-Spark (Resistor) (Used Before Code Date 11070100). |
|
|
Armature-Magneto (Snap In Spark Plug Boot) Used on Type No(s). 0680.1706.1739.1748. 1749.1750.1807.1808. 1816.1823.1824.1825. 1826.1827.1829.1831. 1835.1837.1844.1845. 1846.1847.1849.1850. 1917.1963.1965.2011. 2015.2016.2017.2021. 2028.2035.2041. |
|
|
Armature-Magneto (Screw On Spark Plug Boot) Used on Type No(s). 0680.1706.1739.1748. 1749.1750.1807.1808. 1816.1823.1824.1825. 1829.1831.1835.1837. 1917.1963.1965.2011. 2015.2016.2017.2021. 2028. |
|
|
Armature-Magneto (Snap In Spark Plug Boot) |
|
|
Boot-Spark Plug (Snap On Style) |
|
|
Armature-Magneto Used on Type No(s). 0680.1738.1739.1748. 1749.1750.1807.1808. 1816.1817.1844.1846. 1847.1917.1963.1964. 1965.2011.2021.2034. |
|
|
Housing-Blower (Used Before Code Date 06081400). Used on Type No(s). 1748.1816.1847. 1963. 2011.2012. |
|
|
Housing-Blower (Used After Code Date 06081300). Used on Type No(s). 1748.1816.1827. 1844.1845.1963. 2011,2012. 2041. |
|
|
Housing-Blower (Used Before Code Date 06081400). Used on Type No(s). 0680.1737.1749. 1818.1820.1917. 1966. 2012. 2148. 2149.3170.3185. 3189. |
|
|
Housing-Blower (Used After Code Date 06081300). Used on Type No(s). 0680.1737.1749. 1782.1818.1820. 1917.1966. 2012. 2024. 2035. 2148. 2149.3170.3185. 3189. |
|
|
Housing-Blower Used on Type No(s). 1750. 1807.1817, 1824. 1849.1851, 2016. 2034. |
|
|
Housing-Blower Used on Type No(s). 1738.1739.1808, 1823. 1825.1826. 1964. 2015. 2017. |
|
|
Housing-Blower Used on Type No(s). 1706.1829.1831, 1835.1846.1965, 2018. 2022. 2028. |
|
|
Housing-Blower Used on Type No(s). 1375.1376.1379, 1717. 1718.1719, 1730.1731,1732. 1735. 1754.1781, 1792. 1809.1811. 1959. 1960.1996. 2001. 2108. 2326. 3181.3187.3188. |
|
|
Housing-Blower Used on Type No(s). 1721.1724.1746. 1747.1784.1790. 1830.1837.1841, 1850.1852.1901. 1906.1907.1910. 1911.1912.1913. 1915.1972.1975. 1989. 2019. 2029. 2033. 2320. 2360. 2370. 2384. 2385. 2386. 2389. 2390. 2394.2395. 2641. 2643. 2646. 2649. 2684. 2685. 2686. 3129.3180. 3182. 3308.3309. 3318. 3319.3509. |
|
|
Housing-Blower Used on Type No(s). 0666. 0667. 0868. 0878.1149.1150, 1167.1171.1369. 1548.1559.1569. 1701.1705.1714. 1715.1726.1729. 1755.1766.1777. 1786.1802.1822. 1836.1839.1919. 1926.1932.1941. 1942.1948.1955. 1961.1967.1988. 2005. 2009. 2013. 2014. 2027. 2037. 2038. 2044. 2150. 2320. 2324. 2329. 2331.2333.2334. 2349. 2350. 2367. 2383.2391.2635. 2669. 2673. 2681. 3110.3120.3123. 3133.3138.3140. 3167.3176.3178. 3179. 3183. 3184. 3324. |
|
|
Muffler Used on Type No(s). 1844. |
|
|
Muffler Used on Type No(s). 1706,1738,1739, 1748,1750,1807, 1808,1816,1817, 1823,1824,1825, 1826,1827,1829, 1831,1835,1845, 1846, 1847,1849, 1851,1963,1964, 1965, 2011,2015, 2016, 2017, 2018, 2021, 2022, 2028, 2034, 2041. |
|
|
Bracket-Control Used on Type No(s). 1379,1738,1739, 1767,1781,1782, 1808,1809,1811, 1823,1825,1831, 1840,1841,1911, 1972,1975, 2015, 2017, 2018, 2019, 2024, 2032, 2036, 2037, 2038, 2039, 2040, 2108, 2151, 3188. |
|
|
Bracket-Control Used on Type No(s). 0678, 0679,1746, 1801, 1803,1804, 1805. |
|
|
Bracket-Control (Manual Friction) (Choke A Matic) Used on Type No(s). 1149,1167,1548. |
|
|
Spring-Governor Used on Type No(s). 0670,0680,1706,1720, 1727,1728,1729,1739, 1748,1749,1807,1811, 1814,1818,1820,1821, 1822,1823,1824,1825, 1830,1831,1832,1833, 1835,1840,1841,1844, 1846,1847,1914,1958, 1960,1994,2006,2010, 2015,2016,2021,2023, 2032,2035,2036,2037, 2038,2039,2040,2042, 2043,2108,2379,2380, 3169,3189. |
|
|
Gear-Timing (Plastic) (Used After Code Date 08021700). |
|
|
Gear-Timing (Use Without Woodruff Key) (Used After Code Date 07093000 and Before Code Date 08021800). |
|
|
Gear-Timing (Use Without Woodruff Key) (Used Before Code Date 07100100). |
|
|
Gear-Timing (Uses Woodruff Key) |
|
|
Spring-Governor Used on Type No(s). 0658,0840,0866,0868, 0873,0878,1150,1166, 1171,1320,1365,1366, 1367,1371,1372,1375, 1376,1379,1520,1559, 1717,1718,1719,1723, 1724,1731,1732,1733, 1734,1736,1737,1738, 1750,1758,1760,1763, 1764,1765,1766,1767, 1768,1775,1778,1782, 1785,1790,1791,1792, 1795,1808,1809,1810, 1816,1817,1826,1827, 1829,1837,1839,1845, 1849,1850,1852,1905, 1906,1907,1910,1911, 1912,1913,1915,1916, 1917,1918,1925,1926, 1936,1940,1943,1959, 1962,1963,1964,1965, 1966,1968,1970,1972, 1974,1975,1976,1985, 1991,1992,1993,1995, 1996,1999,2001,2002, 2003,2004,2005,2008, 2011,2012,2014,2017, 2018,2019,2024,2027, 2028,2029,2033,2034, 2041,2148,2149,2151, 2352,3125,3130,3137, 3165,3168,3179,3170, 3181,3185,3186,3314, 3315,3316,3317,3320, 3322,3323,3324,3325. |
|
|
Spring-Govemor Used on Type No(s). 1714,1726,2013,2044, 2367,2673,2635,2681. |
|
|
Gear-Drive (Clockwise) Used on Type No(s). 0823. |
|
|
Spring- Govemor Used on Type No(s). 1715,1777,1786,1836, 1942,1955,1986,2320, 2324,2331,2349,2391, 3178. |
|
|
Spring-Govemor Used on Type No(s). 2383,2683. |
|
|
Spring-Govemor Used on Type No(s). 0652,0656,0661,0662, 0822,0824,0828,0837, 0838,0839,0877,1148, 1315,1316,1322,1324, 1325,1332,1378,1534, 1540,1544,1547,1569, 1570,1571,1721,1751, 1752,1754,1755,1756, 1761,1762,1764,1770, 1771,1781,1784,1789, 1901,1922,1928,1934, 1937,1938,1947,1949, 1967,1977,1978,1982, 1983,1987,1989,1990, 2009,2312,2314,2316, 2319,2323,2326,2328, 2330,2348,2351,2371, 2372,2378,2381,2384, 2385,2386,2387,2388, 2389,2390,2394,2395, 2396,2632,2634,2641, 2642,2643,2644,2645, 2646,2647,2648,2649, 2670,2671,2672,2675, 2676,2680,2682,2684, 2685,2686,3115,3116, 3122,3124,3127,3128, 3129,3132,3172,3173, 3174,3180,3306,3307, 3308,3309,3312,3318, 3319,3509,6699. |
|
|
Spring-Governor Used on Type No(s). 1802. |
|
|
Spring-Governor Used on Type No(s). 0678, 0679. |
|
|
Spring-Governor Used on Type No(s). 1746,1801,1803,1804, 1805. |
|
|
Spring -Governor Used on Type No(s). 1374,1377,1747. |
|
|
Harness-Wiring Used on Type No(s). 2333. 3138. 3179. |
|
|
Spring -Governor Used on Type No(s). 0671,0672. |
|
|
Spring- Governor Used on Type No(s). 0664,0665,0666,0667, 1170,1368,1369,1370, 1373. |
|
|
Cap-End (Used Before Code Date 00040700). |
|
|
Spring -Governor Used on Type No(s). 1149,1548. |
|
|
Housing-Starter (Used Before Code Date 00040700). |
|
|
Spring-Governor Used on Type No(s). 1701. |
|
|
Guard-Muffler (Used Before Code Date 11070100). |
|
|
Spring-Governor Used on Type No(s). 1961,3183. |
|
|
Spring - Governor Used on Type No(s). 1932. |
|
|
Gasket-Roat Bowl (1/16n Thick) |
|
|
Valve-Throttle (Used With Plastic Throttle Shaft) |
|
|
Carburetor (Choke System) (Used Before Code Date 05070100). Used on Type No(s). 1726,1777,1926,1942, 1955,1986,2331,2349. |
|
|
Carburetor (Choke System) (Used After Code Date 05091800). Used on Type No(s). 1726,1777,1836,1926, 1942,1955,1986,2331, 2349. |
|
|
Carburetor (Choke System) Used on Type No(s). 0678,0679,1746,1801, 1802,1803,1804,1805. |
|
|
Carburetor (Choke System) Used on Type No(s). 0664,0665,0666,0667, 0671,0672,1149,1167, 1170,1368,1369,1370, 1373,1374,1377,1548, 1747. |
|
|
Carburetor (Primer System) Used on Type No(s). 0680,1749,1837,1850, 1917,2035. |
|
|
Carburetor (Primer System) Used on Type No(s). 1538. |
|
|
Jet-Main (High Altitude) Used on Type No(s). 0678,0679,1726,1746, 1777,1801,1802,1803, 1804,1805,1836,1926, 1942,1955,1986,2331, 2349. |
|
|
Jet-Main (High Altitude) Used on Type No(s). 0664,0665,0666,0667, 0671,0672,1149,1167, 1170,1368,1369,1370, 1373,1374,1377,1548. |
|
|
Jet-Main (High Altitude) Used on Type No(s). 1538. |
|
|
Jet-Main (Standard) Used on Type No(s). 0678,0679,1726,1746, 1777,1801,1802,1803, 1804,1805,1836,1926, 1942,1955,1986,2331, 2349. |
|
|
Jet-Main (Standard) Used on Type No(s). 0664,0665,0666,0667, 0671,0672,1149,1167, 1170,1368,1369,1370, 1373,1374,1377,1548. |
|
|
Seal-Valve (Used Before Code Date 11070100). |
|
|
Jet-Main (Standard) Used on Type No(s). 1538. |
|
|
Shaft-Choke (Used Before Code Date 08031300). |
|
|
Valve-Choke (Used Before Code Date 08031300). |
|
|
Bushing-Valve Guide (Intake) (Used After Code Date 11063000). |
|
|
Bushing-Valve Guide (Exhaust) (Used Before Code Date 11070100). |
|
|
Bushing-Valve Guide (Intake) (Used Before Code Date 11070100). |
|
|
Shaft-Throttle (Plastic) |
|
|
Shaft-Auxiliarv Drive Used on Type No(s). 1934.1982. 2330. |
|
|
Shaft-Auxiliarv Drive Used on Type No(s). 0662.1315.1538. 1762.2312.2313. 2314.2315.2316. 2351.2352.2360. 2378. 2385. 2394. 3115. 3173. 3319. |
|
|
Camshaft (Counterclockwise) (Used After Code Date 96060200). Used on Type No(s). 0662. 1315.1367. 1538. 1762.1934. 1947. 1949.1982. 1989. 2312.2313. 2314. 2315.2316. 2330. 2351.2352. 2360. 2378. 2385. 2394. 3115. 3173. 3319. |
|
|
Camshaft (Clockwise) (Used Before Code Date 96060300). Used on Type No(s). 0823. |
|
|
Camshaft (Used Before Code Date 96060300). |
|
|
Cover-Blower Housing Used on Type No(s). 2333. 2334. |
|
|
Slinger-Governor/Oil Used on Type No(s). 1167.1715.1961. 2334. 2367. 2673. 3183. |
|
|
Valve-Intake (Used Before Code Date 11070100). |
|
|
Valve-Exhaust (Used Before Code Date 11070100). |
|
|
Rod- Connecting (Standard) (Used Before Code Date 97011300). |
|
|
Rod- Connecting (Standard) (Used After Code Date 97011200 and Before Code Date 09041700). |
|
|
Pin-Piston (.005\" Oversize) (Used Before Code Date 97011300). |
|
|
Pin-Piston (Standard) (Used Before Code Date 97011300). |
|
|
Pin-Piston (Standard) (Used After Code Date 97011200 and Before Code Date 09041700). |
|
|
Lock-Piston Pin (Used Before Code Date 97011300). |
|
|
Lock-Piston Pin (Used After Code Date 97011200 and Before Code Date 09041700). |
|
|
Ring Set (.030\" Oversize) (Used Before Code Date 97011300). |
|
|
Ring Set (.020\" Oversize) (Used Before Code Date 97011300). |
|
|
Ring Set (.020\" Oversize) (Used After Code Date 97011200 and Before Code Date 04102200). |
|
|
Ring Set (.020\" Oversize) (Used After Code Date 04102100 and Before Code Date 07090400). |
|
|
Ring Set (.020\" Oversize) (Used After Code Date 07090300 and Before Code Date 09041700). |
|
|
Brake (Used Before Code Date 08050100). Used on Type No(s). 0680.1700.1706. 1721.1724.1737. 1746.1747.1748. 1749.1753.1782. 1816.1818.1820. 1827.1829.1830. 1831.1835.1837. 1841.1844. 1845. 1846.1850.1852. 1906.1907.1908. 1910.1911.1912. 1913.1915.1917. 1930.1963.1965. 1966.1972.1975. 2011.2012. 2018. 2019. 2021.2022. 2024. 2028. 2029. 2033. 2035. 2041, 2148. 2149.2308. 2639.3170. 3185. 3189.3509. |
|
|
Ring Set (.020\" Oversize) (Used After Code Date 09041600 and Before Code Date 11070100). |
|
|
Ring Set (.020\" Oversize) (Used After Code Date 11063000). |
|
|
Cover-Linkage (Used Before Code Date 07072300). |
|
|
Ring Set (Standard) (Used Before Code Date 97011300). |
|
|
Ring Set (Standard) (Used After Code Date 97011200 and Before Code Date 04031500). |
|
|
Ring Set (Standard) (Used After Code Date 04031400 and Before Code Date 07090400). |
|
|
Ring Set (Standard) (Used After Code Date 07090300 and Before Code Date 09041700). |
|
|
Ring Set (Standard) (Used After Code Date 09041600 and Before Code Date 11070100). |
|
|
Piston Assembly (.030\" Oversize) (Used Before Code Date 97011300). |
|
|
Piston Assembly (.020\" Oversize) (Used Before Code Date 97011300). |
|
|
Piston Assembly (.020\" Oversize) (Used After Code Date 97011200 and Before Code Date 07090400). |
|
|
Cap-Fuel Tank (Plastic) Used on Type No(s). 2384. 3312. 3318. 3319. |
|
|
Piston Assembly (.020\" Oversize) (Used After Code Date 07090300 and Before Code Date 09041700). |
|
|
Piston Assembly (.020\" Oversize) (Used After Code Date 09041600 and Before Code Date 11070100). |
|
|
Piston Assembly (.020\" Oversize) (Used After Code Date 11063000). |
|
|
Piston Assembly (Standard) (Used Before Code Date 97011300). |
|
|
Piston Assembly (Standard) (Used After Code Date 97011200 and Before Code Date 07090400). |
|
|
Piston Assembly (Standard) (Used After Code Date 07090300 and Before Code Date 09041700). |
|
|
Piston Assembly (Standard) (Used After Code Date 09041600 and Before Code Date 11070100). |
|
|
Flywheel Used on Type No(s). 1375.1376.1379. 1717.1718.1719. 1730.1731.1732. 1735.1754.1781. 1792.1795.1809. 1811.1959.1960. 1996. 2001.2002. 2042. 2043. 2108. 2326.3181.3187. 3188. |
|
|
Flywheel Used on Type No(s). 0667. 0878.1149. 1167.1369.1548. 1559.1569.1701. 1714.1715.1726. 1729.1750.1786. 1802.1807.1817. 1822.1824.1836. 1849.1919.1932. 1941.1942.1948. 1955.1961.1967. 2005. 2009. 2013. 2016. 2037. 2038. 2044. 2320. 2324. 2331. 2333. 2349. 2367.2383.2391. 2635. 2669. 2673. 2681.3133. 3178. 3179.3183.3324. |
|
|
Crankshaft Used on Type No(s). 2037.2038. |
|
|
Crankshaft Used on Type No(s). 1706.2151. |
|
|
Crankshaft Used on Type No(s). 2320. |
|
|
Tank-Fuel (Plastic) Used on Type No(s). 1375.1376.1379. 1717.1718.1719. 1730.1731.1732. 1735.1754.1781. 1792.1795.1959. 1960.1996. 2001. 2002. 2042. 2043. 2108.2326. 3181. 3187. 3188. |
|
|
Crankshaft Used on Type No(s). 1720.1776.1778.1840. 1841.2032.2036.2039. 2040. |
|
|
Crankshaft Used on Type No(s). 1836.2331.2333.2681. |
|
|
Crankshaft Used on Type No(s). 1714.1726.2013.2044. 2349.2383.2391.2635. 2683. |
|
|
Crankshaft Used on Type No(s). 1777. |
|
|
Crankshaft Used on Type No(s). 1955.1986.3178. |
|
|
Crankshaft Used on Type No(s). 1717.1767.1768.1775. |
|
|
Crankshaft Used on Type No(s). 1961.2329.2334. 3183 |
|
|
Crankshaft Used on Type No(s). 1766. |
|
|
Crankshaft (Used Before Code Date 97011300). Used on Type No(s). 1149.1548. |
|
|
Crankshaft (Used After Code Date 97011200). Used on Type No(s). 1149.1548.1701.1925. 2312.2313.2314.2315. 2316.2324.2328.2352. 2360.2370.2373.2381. 2383.2384.2394.2395. 2396.3172.3173.3180. 3318.3319. |
|
|
Kit-Label (Touch N Mow) |
|
|
Crankshaft (Used Before Code Date 97011300). Used on Type No(s). 0866.0868.0873.0877. 1166.1170.1332.1366. 1368.1370.1371.1544. 1559.1569.1977. |
|
|
Crankshaft (Used After Code Date 97011200). Used on Type No(s). 0664.0665.0666.0670. 0671.0672.0680.0840. 0866.0868.0873.0877. 0878.1150.1166.1170. 1171.1320.1326.1332. 1366.1368.1370.1371. 1372.1374.1375.1376. 1377.1378.1379.1544. 1559.1569.1723.1727. 1730.1731.1733.1734. 1736.1737.1738.1739. 1740.1748.1749.1770. 1771.1784.1785.1786. 1790.1794.1795.1801. 1803.1804.1805.1810. 1811.1814.1816.1818. 1821.1823.1825.1826. 1827.1829.1830.1831. 1832.1835.1837.1839. 1844.1845.1846.1847. 1849.1852.1914.1917. 1919.1920.1926.1932. 1935.1936.1941.1942. 1943.1947.1948.1958. 1959.1962.1964.1965. 1966.1967.1970.1973. 1976.1977.1983.1985. 1988.1991.1992.1993. 1994.1995.1996.2001. 2002.2006.2008.2009. 2010.2012.2014.2015. 2017.2023.2027.2028. 2035.2042.2043.2108. 2148.2149.2350.2644. 2669.2676.3130.3132. 3137.3166.3169.3170. 3181.3185.3186.3189. 3313.3314.3315.3320. 3322.3323.3325. |
|
|
Operator\'s Manual (Used Before Code Date 11070100). |
|
|
Operator\'s Manual (Touch N Mow) |
|
|
Crankshaft (Used Before Code Date 97011300). Used on Type No(s). 0658.0660.1758. |
|
|
Kit-Screw/ Washer (Touch N Mow) |
|
|
Crankshaft (Used After Code Date 97011200). Used on Type No(s). 0658.0660.1570.1758. 1760.1763.2670. |
|
|
Gasket Set-Valve (Used Before Code Date 11070100). |
|
|
Crankshaft (Used Before Code Date 97011300). Used on Type No(s). 0823.1520.1530.1531. 1532.1533.1567.2630. 2631. |
|
|
Pilot-Guide Used on Type No(s). 1955. 1961.2681. 3183. |
|
|
Crankshaft (Used After Code Date 97011200). Used on Type No(s). 0823.1520.1530.1531. 1532.1533.1567.1705. 1718.1746.1747.1751. 1769.1782.1850.1851. 1905.1906.1907.1910. 1911.1912.1913.1915. 1916.1918.1923.1939. 1940.1950.1951.1952. 1972.1975.1979.1980. 1987.2018.2019.2024. 2029.2150.2313.2375. 2376.2379.2380.2609. 2610.2611.2612.2630. 2631.2649.2667.2677. 2678.2679.2686.3120. 3123.3138.3140.3167. 3176.3184.3187.3188. |
|
|
Crankshaft (Used Before Code Date 97011300). |
|
|
Screw (Cylinder Head) (Used Before Code Date 11070100). |
|
|
Gasket-Beather (Used Before Code Date 11070100). |
|
|
Beather-Assembly (Used Before Code Date 11070100). |
|
|
Starter-Mechanical (Touch N Mow) (Do Not Service Individual Parts. Only As A Whole) Used on Type No(s). 2001. |
|
|
Gasket-Cylinder Head (Used Before Code Date 11070100). |
|
|
Head-Cylinder (Used Before Code Date 11070100). |
|
|
Sump-Engine Used on Type No(s). 1375.1376.1379. 1717.1718.1719. 1730.1731.1732. 1735.1754.1781. 1792.1795.1809, 1811.1959.1960. 1996. 2002. 2042. 2043. 2108. 2326. 3181.3187. 3188. |
|
|
Sump-Engine Used on Type No(s). 1167.1715.1955. 1961.2320.2324. 2331.2367. 2673. 2681.3182. |
|
|
Cylinder Assembly (Used Before Code Date 11070100). |
