| 1 | SPRING |
| 2 | SPRING RETAINER |
| 3 | LINK |
| 4 | COLLAR SCREW |
| 5 | STEERING WHEEL |
| 6 | SCREW IHSETM |
| 7 | HEXAGON NUT |
| 8 | STEERING ROD |
| 9 | DRIVER |
| 10 | SCREW IHSETM |
| 12 | SPACER |
| 13 | BALL BEARING |
| 14 | SCREW EHHFM |
| 15 | PULLEY |
| 16 | PULLEY |
| 17 | CIRCLIP |
| 19 | BUSHING |
| 20 | SCREW EHHFM |
| 21 | WASHER |
| 22 | WIRE ASSY |
| 23 | STARTER PULLEY |
| 24 | SHAFT |
| 25 | E-CLIP |
| 26 | CHAIN |
| 27 | LINKAGE |
| 28 | WIRE GUIDE |
| 29 | HEXAGON NUT |
| 30 | SPINDLE |
| 31 | BALL BEARING |
| 32 | BALL BEARING |
| 33 | CIRCLIP |
| 34 | CIRCLIP |
| 35 | SWING AXLE |
| 37 | WASHER |
| 38 | V-RING |
| 39 | BRACKET |
| 40 | NUT |
| 41 | SCREW EHHFM |
| 42 | PROTECTIVE COVER |
| 43 | NUT |
