Схема BLUEWELD VEGAMIG 203/2 TURBO (821475) 01 Полуавтомат

1 Potenziometro 10K Potentiometre 10K Potentiometer 10K Potentiometer 10K Resistencia Electrica Variable 10K
2 Manopola Poignee Knob Griff Manija
3 Basetta Cambio Tensione Platine Pour Changer Tension Changing Voltage Card Wechselspannungskarte Base Cambio Tension
4 Protezione Raddrizzatore Protection Redresseur Rectifier Protection Gleichrichterschutz Proteccion Rectificador
5 Raddrizzatore Redresseur Rectifier Gleichrichter Rectificador
6 Kit Scheda Controllo Kit Fiche De Controle Control Pcb Kit Kontrollekarte Kit Kit Tarjeta De Controlo
7 Deviatore A Levetta Interrupteur A Levier Switch Schalter Interrupteur A Levier
8 Assieme Manopola Per Commutatore Set Poigne Pour Commutateur Switch Knob Set Umschaltergriff Set Set Manjia Para Conmutador
10 Termostato Thermostat Thermostat Thermostat Termostato
12 Fusibile Fusible Fuse Sicherung Fusible
13 Commutatore Commutateur Switch Schalter Conmutador
14 Elettrovalvola Electrovanne Electro-valve Elektroventil Electrovalvola
15 Teleruttore Telerupteur Contactor Schuetz Contactor
16 Lampada Gialla Temoin Lumineaux Jaune Yellow Pilot Lamp Gelbe Kontrollampe Piloto Amarillo
17 Cavo 16 Mmq 2 M Cable 16 Mmq 2 M Cable 16 Mmq 2 M Kabel 16 Mmq 2 M Cable 16 Mmq 2 M
18 Cavo Alim. 4G2.5 2 M Cable Alim. 4G2.5 2 M Mains Cable 4G2.5 2 M Netzkabel 4G2.5 2 M Cable Alim. 4G2.5 2 M
19 Ventola Helice Fan Blade FlÜgelrad Aventador
20 Motore Ventilatore Moteur Ventilateur Fan Motor Ventilatormotor Motor Ventilacion
21 Motorino Trainafilo Moteur Pour Devidoir Wire Feed Motor Drahtvorschubmotor Motor Por Arrastre Hilo
22 Trasformatore Transformateur Transformer Transformator Transformador
23 Trasformatore Ausiliario Transformateur Auxiliaire Auxiliary Transformer Hilfstransformator Transformador Ausiliario
25 Controrullino Contre Galet Pressure Roll Gegenrolle Contra Roldana
26 Volantino Per Aspo Volant Pour Support Bobine Reel Handwheel Wicklerhandrad Volant Por Aspa
27 Aspo Support Bobine Reel Wickler Aspa
28 Kit Pressacavo Kit Presse Cable Cable Bushing Kit Kabelhalter Kit Kit Prensa Cable
29 Supporto Rullino Support Galet Roll Support Rollenhalter Sosten Roldana
30 Cuffia Fissaggio Torcia Couvre Fixage Torche Torch Fixing Casing Brennerbefestigungskasten Cubierta Por Fijador Antorcha
31 Staffa Controrullino Bride Contre-galet Pressure Roll Bracket GegenrollenbÜgel Estribo Contra-roldana
32 Distanziale Entretoise Spacer Abstandstueck Anillo Por Distanciar
33 Ruota Fissa Roue Fixe Fixed Wheel Fixes Rad Rueda Firme
34 Ruota Roue Wheel Rad Rueda
35 Cornice Cadre Frame Rahmen Marco
37 Volantino Per Traino Volant Pour Devidoir Wire Feed Handwheel Vorschubhandrad Volant Por Arrastre
38 Cavallotto Etrier Support BÜgelbolzen Sosten
39 Supporto Girevole Support Tournant Swivel Support Drehbarerhalter Sosten Giratorio
40 Adattatore Bombola Argon It Adapteur Bouteille Argon It Argon Gas Bottle It Adaptor Argongasflasche It Passtueck Adaptador Bombona Argon It
41 Molla Ressort Spring Feder Muelle
42 Molla Per Aspo Ressort Pour Support Bobine Reel Spring Wicklerfeder Muelle Por Aspa
43 Manico Poignee Handle Handgriff Manija
44 Retro Partie Arriere Back Panel Rueckseite Trasera
45 Diaframma Diaphragme Diaphragm Diaphragma Diafragma
46 Staffa Per Bombola Etrier Pour Bouteille Bracket For Bottle Buegel Fuer Flasche Estribo Para Bombona
47 Frontale Partie Frontal Front Panel Geraetefront Frontal
48 Fondo Chassis Bottom Bodenteil Fondo
49 Kit Mantello Kit Capot Cover Kit Deckelkit Kit Panel De Cobertura
51 Kit Sportello Kit Guichet Door Kit Tuer Kit Kit Portezuela
52 Asse Per Ruote Axe Roues Wheels Axle Radachse Eje Ruedas
53 Toledo 250A Pinza Di Massa Toledo 250A Pince De Masse Toledo 250A Work Clamp Toledo 250A Masseklemme Toledo 250A Pinza De Masa
54 Rullino Traino D. 0,6-0,8 Mm Galet D’entrainement D. 0,6-0,8 Mm Feed Roll D. 0,6-0,8 Mm Vorschubrolle D. 0,6-0,8 Mm Roldana Por Arrastre D. 0,6-0,8 Mm
55 Riduttore Pressione Bombola Ricar. Reducteur Pression Bouteille Recharg. Gas Regulator Refillable Bottle Druckminderer Auffuellbare Flasche Reductor Presion Bombona Recargar
56 Mt15 Torcia Mig 3 M 220 A Mt15 Torche Mig 3 M 220 A Mt15 Mig Torch 3 M 220 A Mt15 Mig Brenner 3 M 220 A Mt15 Antorcha Mig 3 M 220 A
57 Attacco Torcia Attelage Torche Torch Connection Schlauchpaketanschluss Enganche Antorcha
60 Kit Guaina Entrata Motore Kit Gaine Entree Moteur Gas Hose Kit Drahtfuehrungsseelekit Kit Vaina Guiadera Alambre
61 Kit Ingranaggi Kit Engrenages Gears Kit ZahnrÄder Kit Kit Engranajes
62 Kit Aspo Kit Support Bobine Reel Kit Wickler Kit Kit Aspa
