| 1 | KEYLESS DRILL CHUCK |
| 2 | BEARING RETAINER 19-36 |
| 3 | SPINDLE |
| 4 | BALL BEARING 6202LLB |
| 5 | RETAINING RING S-15 |
| 6 | HEX. BOLT M8X120 |
| 7 | GRIP BASE |
| 8 | GRIP 36 COMPLETE |
| 9 | HEX. WASHER |
| 10 | TAPPING SCREW 4X35 |
| 11 | GEAR HOUSING |
| 12 | BALL BEARING 606ZZ |
| 13 | GEAR COMPLETE |
| 14 | BALL BEARING 606ZZ |
| 15 | SPUR GEAR 29-37 |
| 16 | BALL BEARING 608ZZ |
| 17 | SEAL RING |
| 18 | GEAR HOUSING COVER COMPLETE |
| 19 | O RING 12 |
| 20 | CHANGE LEVER B |
| 21 | PIN 4 |
| 22 | LEAF SPRING |
| 23 | LOCK PLATE |
| 24 | RACK 12 |
| 25 | CHANGE PLATE B |
| 26 | PIN 4 |
| 27 | RING 8 |
| 28 | BALL BEARING 608DDW |
| 29 | FAN 52 |
| 30 | ARMATURE ASS\\\'Y 220-240V INC. 27,28,29,31,32 |
| 31 | INSULATION WASHER |
| 32 | BALL BEARING 607LLB |
| 33 | RUBBER RING 19 |
| 34 | BAFFLE PLATE |
| 35 | TAPPING SCREW 4X65 |
| 36 | FIELD 220-240V |
| 37 | MOTOR HOUSING |
| 38 | CAP |
| 40 | CARBON BRUSH CB-419 |
| 41 | BRUSH HOLDER |
| 42 | DP4011 NAME PLATE |
| 43 | SPACER |
| 44 | BRUSH HOLDER |
| 45 | SWITCH TG813ALB-2 |
| 46 | HANDLE COVER COMPLETE |
| 47 | TAPPING SCREW 4X25 |
| 48 | TAPPING SCREW 4X18 |
| 49 | STRAIN RELIEF |
| 50 | NOISE SUPPRESSOR |
| 51 | CORD GUARD 8 |
| 52 | POWER SUPPLY CORD 1.0-2-2.5 |
| A01 | DEPTH GAUGE |
