| 1 | Rating plate |
| 2 | Housing w.cover |
| 3 | Electronic switch,18V |
| 4 | Switch-on lock |
| 5 | Washer |
| 6 | Pressure lever |
| 7 | Balancing plate |
| 8 | Needle bearing |
| 9 | Washer |
| 10 | Retaining ring |
| 11 | Gasket |
| 12 | Spring washer |
| 13 | Fillister head screw |
| 14 | Fillister head screw |
| 15 | Switch slide |
| 16 | Pressure plate |
| 17 | Spring clip |
| 18 | Pinion shaft compl. |
| 19 | Lever compl. |
| 20 | Gear housing compl. |
| 21 | Motor compl. |
| 22 | Hexagonal nut |
| 23 | Cylindrical pin |
| 24 | Washer |
| 25 | Washer |
| 26 | Gear wheel |
| 27 | Needle bearing compl. |
| 28 | Fillister head screw |
| 29 | Washer |
| 30 | Gear-box cover cpl. |
| 31 | Hexagonal key |
| 32 | Key holder |
| 33 | Base plate compl. |
| 34 | Clamping claw |
| 35 | Cap screw |
| 36 | Spring washer |
| 37 | Slide block |
| 38 | Anti-splintering insert |
| 39 | Supporting lever compl. |
| 40 | Cylindrical pin |
| 41 | Self-tap. fill. h. screw |
| 42 | Part not needed |
| 43 | Fillister head screw |
| 44 | Clamping lever cpl. |
| 45 | Cover |
| 46 | Protective strap |
| 880 | Grease 50Gr 1,8oz |
| 1001 | Wiring diagram |
