1 |
PUMP CRANKCASE \\\"44\\\" |
|
2 |
BALLBEARING 6305 |
|
3 |
O-RING D. 55.56 X 3.53 NBR 70SH |
|
4 |
SPACER \\\"44\\\" |
|
5 |
SCREW TEM6X10ZC. UNI 5739 |
|
6 |
CRANKASE COVER W 70 |
|
7 |
NUT M8X1,25 X13X5 S2 INX |
|
8 |
WASHER D. 8X13X1 |
|
9 |
PISTON D.15 TURBO 14.160 |
|
10 |
O-RING D. 5.28 X 1.78 VIT 70SH |
|
11 |
ANTI-EXTR.RING WW161 |
|
12 |
WASHER D.16 X28 X1 PVC |
|
13 |
PISTON GUIDE \\\"44\\\" |
|
14 |
GUDGEON D.10X29.5 \\\"44\\\" |
|
15 |
CONNECTING ROD \\\"44\\\" |
|
16 |
CAP 1/4X9MWW90 |
|
17 |
O-RING D. 10.82 X 1.78 NBR 70SH |
|
18 |
SCREW TCEI 6X14 UNI 5931 |
|
19 |
CRANKASE COVER \\\"44\\\" |
|
20 |
O-RING D. 101.27 X 2.62 NBR 70SH |
|
21 |
KEY \\\"44” |
|
22 |
SHAFT \\\"44й WW 186 |
|
23 |
OIL DIPSTICK W 70 |
|
24 |
OIL SEAL 25X 62X10 NBR70 |
|
25 |
CAP M24X1.5X17 \\\"44\\\" |
|
26 |
PRESSURE GAUGE 0-300 D.40 |
|
27 |
VALVE UNIT \\\"44\\\" WW136-186 |
|
28 |
O-RING D. 20.24 X 2.62 NBR 70SH |
|
29 |
CAP M24X1.5X17 \\\"44\\\" F.1/8 |
|
30 |
ANTI-EXTR.RING D. 10.6X15X2 |
|
31 |
O-RING D. 9.92 X 2.62 VIT 70SH |
|
32 |
VALVE SEAT CONTROL SET W1 |
|
33 |
SCREW M 5X0,8X7,5 |
|
34 |
VALVE CLT |
|
35 |
O-RING D. 6.75 X 1.78 VIT 80SH |
|
36 |
ANTI-EXTR.RING D.22 X25X1,5 |
|
37 |
O-RING D. 21.91 X 1.78 NBR 70SH |
|
38 |
VALVE GUIDE \\\"44\\\" |
|
39 |
VALVE \\\"44\\\" |
|
40 |
SPRING D. 18.5X11 \\\"44й |
|
40 |
SPRING D. 18.5X11 \\\"44й |
|
41 |
SPACER \\\"44\\\" |
|
41 |
SPACER \\\"44\\\" |
|
42 |
ANTI-EXTR.RING HM |
|
42 |
ANTI-EXTR.RING HM |
|
43 |
CONTROL PISTON \\\"44\\\" |
|
43 |
CONTROL PISTON \\\"44\\\" |
|
44 |
O-RING D. 9.13 X 2.62 VIT70SH |
|
44 |
O-RING D. 9.13 X 2.62 VIT70SH |
|
45 |
ANTI-EXTR.RING D. 9,5X14X1,5 |
|
45 |
ANTI-EXTR.RING D. 9,5X14X1,5 |
|
46 |
O-RING D. 23.81 X 2.62 NBR 70SH |
|
46 |
O-RING D. 23.81 X 2.62 NBR 70SH |
|
47 |
BUSHING \\\"44\\\" |
|
47 |
BUSHING \\\"44\\\" |
|
48 |
SPRING PLATE \\\"44\\\" INF. |
|
48 |
SPRING PLATE \\\"44\\\" INF. |
|
49 |
SPRING D. 7.6X29 \\\"44\\\" |
|
49 |
SPRING D. 7.6X29 \\\"44\\\" |
|
50 |
SPRING D. 15X35 |
|
50 |
SPRING D. 15X35 |
|
51 |
SPRING PLATE W1 |
|
51 |
SPRING PLATE W1 |
|
52 |
REGISTER COLT |
|
52 |
REGISTER COLT |
|
53 |
O-RING D. 20.35 X 1.78 NBR 70SH |
|
53 |
O-RING D. 20.35 X 1.78 NBR 70SH |
|
54 |
SCREW EI-ST 8X20 UNI5923 |
|
54 |
SCREW EI-ST 8X20 UNI5923 |
|
55 |
NUT M 8 UNI 5589 |
|
55 |
NUT M 8 UNI 5589 |
|
59 |
FLANGE MOTOR 4P H100 ELT |
|
59 |
FLANGE MOTOR 4P H100 ELT |
|
60 |
EL.MOT. ROTOR 5.5HP T 2P 5/60HZ |
|
60 |
EL.MOT. ROTOR 5.5HP T 2P 5/60HZ |
|
61 |
EL.MOT. STATOR ELT 5.5HP 380V 50HZ 2P |
|
61 |
EL.MOT. STATOR ELT 5.5HP 380V 50HZ 2P |
|
62 |
O-RING D. 9.12 X 3.53 NBR 70SH |
|
62 |
O-RING D. 12.37 X 2.62 NBR 70SH |
|
62 |
O-RING D. 9.12 X 3.53 NBR 70SH |
|
62 |
O-RING D. 12.37 X 2.62 NBR 70SH |
|
63 |
PLIERS ELT |
|
63 |
PLIERS ELT |
|
64 |
CABLE CLAMP ELITE |
|
64 |
CABLE CLAMP ELITE |
|
65 |
CABLE ELT TR. 5.3MT |
|
65 |
CABLE ELT TR. 5.3MT |
|
67 |
SWITCH ISK MS-MT 25 10-16 A |
|
67 |
SWITCH ISK MS-MT 25 10-16 A |
|
68 |
CONTROL COVER ELT |
|
68 |
CONTROL COVER ELT |
|
69 |
MAMBRANE ELT |
|
69 |
MAMBRANE ELT |
|
70 |
BASE COVER ELT II |
|
70 |
BASE COVER ELT II |
|
71 |
SCREW TCEI 5X70 UNI5931 |
|
71 |
SCREW TCEI 5X70 UNI5931 |
|
72 |
SCREW TCB-TC 2.9X 9.5 UNI6954 |
|
72 |
SCREW TCB-TC 2.9X 9.5 UNI6954 |
|
73 |
SCREW TCB-TC 4.2X16 UNI6954 |
|
73 |
SCREW TCB-TC 4.2X16 UNI6954 |
|
74 |
SCREW TCB-TC 5X12 |
|
74 |
SCREW TCB-TC 5X12 |
|
75 |
WASHER D. 5.3X9X0.6 |
|
75 |
WASHER D. 5.3X9X0.6 |
|
76 |
BALLBEARING 62062Z |
|
76 |
BALLBEARING 62062Z |
|
77 |
CIRCLIP VEDI 10405 |
|
77 |
CIRCLIP VED110405 |
|
79 |
IMPELLER ELT |
|
79 |
IMPELLER ELT |
|
80 |
FAN COVER ELT |
|
80 |
FAN COVER ELT |
|
81 |
CIRCLIP D. 28 UNI 7435 |
|
81 |
CIRCLIP D. 28 UNI 7435 |
|
82 |
SCREW TCB-TC 5X45 UNI7687 |
|
82 |
SCREW TCB-TC 5X45 UNI7687 |
|
83 |
O-RING D. 28.25 X 2.62 NBR 70SH |
|
85 |
SCREW TCEI6X18 |
|
86 |
WASHER D. 6,4X10X0,7 |
|
87 |
SCREW TCEI 6X25 UNI5931 |
|
88 |
NOZZLE D. 2.2 |
|
89 |
O-RING D. 13.95 X 2.62 VIT70SH |
|
90 |
NIPPLE VEDI9721 |
|
91 |
O-RING D. 9.25 X 1.78 NBR 70SH |
|
92 |
SPRING D. 4.3X11 X7.3 KR |
|
93 |
BALL D. 7/32 |
|
94 |
METERING. BODY \\\"44\\\" |
|
95 |
VALVE SEAT KR |
|
96 |
KNOB \\\"44\\\" |
|
97 |
O-RING D. 4.48 X 1.78 NBR 70SH |
|
98 |
CAP D. 8 \\\"44\\\" |
|
99 |
FILTER \\\"44” |
|
100 |
O-RING D. 13.10 X 2.62 NBR 70SH |
|
101 |
HOSE FITTING \\\"44\\\" |
|
102 |
O-RING D. 17.13 X 2.62 NBR 70SH |
|
103 |
NIPPLE G 3/4 CLT |
|
104 |
FILTER D. 15X37 |
|
105 |
O-RING D. 12.37 X 2.62 NBR 70SH |
|
106 |
HOSE FITTING HBX |
|
107 |
RING NUT 3/4 COLT |
|
112 |
CAP G 1/8 KR |
|
113 |
SCREW TCEI 8X60 UNI5931 |
|
114 |
WASHER D. 8 TC |
|
115 |
HEAD \\\"44\\\" WWD.15 V.l. |
|
116 |
WASHER D.21,5X27 ALL |
|
117 |
CAP 1/2X10 M |
|
118 |
OIL SEAL 20X 30X 5 NBR70 |
|
119 |
WASHER D.17,05X22,3 X1,5 |
|
120 |
CAP 3/8X13 MWW90 |
|
121 |
HEAD RING D. 15 |
|
122 |
PACKING D. 15 TURBO |
|
123 |
PACKING D. 15 RESTOP |
|
124 |
INTERMED. RING D. 15 TURBO |
|
125 |
PACKING RETAIN.D. 15 \\\"44\\\" |
|
126 |
O-RING D. 31.47 X 1.78 NBR 70SH |
|
128 |
PLATE ELT ISK |
|
149 |
PACKING D. 15 L.P. |
